Overview
- Condition: New vehicle
- Manufacturer: Honda
- Model: Work / Industrial EM6500S2CT2
- Year: 2024
- Stock #: X00009
- Type: Generators
Specifications
- Generator Type: Brush type
- Maximum AC Output (Watts): 6,500
- AC Voltage Available: 120 / 240
- Maximum Continuous AC Output (Watts): 5,500 7,000 (iAVR)
- Max. Rated AC Amperage @ 120 V / 240 V: 45.8 / 22.9 (58.3 / 29.2 for 10 sec. iAVR)
- Ground Fault Circuit Interrupter (GFCI): N/A
- Frequency (Hertz): 60
- Automatic Voltage Regulator: Standard iAVR (Intelligent Automatic Voltage Regulator)
- DC Output Volts / Amps: 12 / 8
- Common Duplex Receptacle Specifications: 40 amps/120 VAC continuous is available as combined total from these twin duplex AC receptacles. Maximum of 20 amps available from each GFCI duplex receptacle.
- DC Receptacle Specifications: 8 amps/12 VDC is available from these +/- thumb screw terminals. Important Note: AC and DC output can be used simultaneously on this series only. DC system uses floating N (Neutral) type.
- DC Charging Cable: Optional (P/N 32650-825-015)
- High Capacity 120 / 240 VAC Twist Lock Receptacle Specifications: This receptacle (NEMA # L5-30R) will supply 30 amps at 120 VAC continuously. This receptacle (NEMA # L14-30R) will supply 22.9 amps (5.5 kVA) at 240 VAC continuously.
- Engine Type: Honda iGX390T2 OHV, 4-stroke, air-cooled
- Displacement: 389 cc
- Starting System: Electric/recoil
- Low Level Oil Alert System: Standard
- Auto Throttle: Standard
- Remote Start Capability: Optional
- Fuel Tank Capacity: 23.5 litres (5.17 Imp. gal.)
- Transport Wheels: 2 Wheel standard
- Lifting Hook: Optional (P/N 06810-Z22- A30ZA)
- Battery: Standard (P/N 31500-MCR-J01)
- Approximate Running Time (hrs.) / Tankful: 6.9** / 10.4****
- Rated Fuel Consumption (litres/hr): 3.40**
- Noise Level dB(A) (1.5 m to 7 m): 73**
- Length (Without Handles and Wheels): 681 mm (26.8 in.)
- Length (With Handles and Wheels): 1,051 mm (41.4 in.)
- Width (Without Handles and Wheels): 530 mm (20.9 in.)
- Width (With Handles and Wheels): 706 mm (27.8 in.)
- Height (Without Lift-Hook): 719 mm (28.3 in.)
- Height (With Lift-Hook): 773 mm (30.4 in.) optional lift hook
- Dry Weight: 104.8 kg (231 lbs.)
- Cold Climate Technology: Standard
- ** / ***: **At max. rated output (continuous) in Watts. ****At 50% rated output (continuous) in Watts.
Notes
Notes:
Honda EM6500 Generator. Financing available, OAC. Freight and PDI extra. All rebates to dealer.
### 2024 Honda Power Generators Home Back-up EM6500S2CT1
The Electric Start 6500 has premium features for demanding commercial usage (non-GFCI applications) and reliable home backup use.
**Features may include:**
* Portable power with premium features and traditional Honda durability and performance
* Powerful, easy-start Honda iGX390 commercial-grade engine
* Cold Climate TechnologyTM aids continuous running in cold weather conditions
* 6,500 watts maximum AC output
* Auto-throttle further extends running time by automatically adjusting engine speed to idle when under no load
* Auto-throttle further extends running time by automatically adjusting engine speed to idle when under no load
* Standard wheel kit with positive lock folding handles for easy transportation and convenient, compact storage
Honda exclusive iAVR (Intelligent Auto Voltage Regulation) system for stable power delivery and available extra wattage (7,000 watts for 10 seconds to start larger equipment)
